10G XFP CWDM

CWDM XFP optical transceivers are designed for Storage, IP network and LAN. The CWDM XFP is a fully integrated 8G~10Gbps~11.1 optical transceiver module. This transceiver uses an cooled CWDM EML Laser to achieve 80km over standard single mode fiber. Some models are using DFP 10G CWDM laser. The most commonly used CWDM XFP wavelengths are from 1270nm to 1610nm with steps of 20nm (XFP 1270, XFP 1290, XFP 1310, XFP 1330, XFP 1350, XFP 1370, XFP 1390, XFP 1410, XFP 1430, XFP 1450, XFP 1470, XFP 1490, XFP 1510, XFP 1530, XFP 1550, XFP 1570, XFP 1590, XFP 1610). The transmission distance depends on the wavelength, the fiber type and the MUX/DEMUX insertion loss. Distance can reach up to 80km.

    Part No.

    Description

    Data Rate

    Wavelength

    Distance

    Connector

    Temp

    Download

    LXF-Cxx-40D

    CWDM XFP ER

    9.95~10.3Gbps

    1470~1610nm

    40KM

    LC

    C


    LXF-Cxx-80D

    CWDM XFP ZR

    9.95~10.3Gbps

    1470~1610nm

    80KM

    LC

    C



    For the latest specification and samples, please contact us [email protected]
